Infineon EconoPACK Thyristor FS225R12KE3 IGBT Inverter Module Potential 1200V 225A

Description

Infineon EconoPACK Thyristor FS225R12KE3 IGBT Inverter Module Potential 1200V 225A

FS225R12KE3

1200 V, 225 A sixpack IGBT module

Overview

EconoPACK™ + B-series 1200 V, 225 A sixpack IGBT module with TRENCHSTOP™ IGBT3 and Emitter Controlled HE diode.

Summary of Features:
a:Easy separation of DC and AC
b:Optimized Thermal Resistance Case to Heat Sink
c:Highest Power Density for compact Inverter Designs

Benefits
Compact modules
a:Easy and most reliable assembly
b:No plugs and cables required
c:Ideal for low inductive system designs

Potential Applications
a:Motor control and drives
b:Solutions for solar energy systems
c:Commercial, construction and agricultural vehicles (CAV)
d:Uninterruptible power supply (UPS)

Specifications

Parametrics	FS225R12KE3
Dimensions (width)	150 mm
Dimensions (length)	162 mm
Features	Solder Pin
Housing	EconoPACK™ + B
IC(nom) / IF(nom)	225 A
IC max	225 A
Qualification	Industrial
Technology	IGBT3 - E3
VCE(sat) (Tvj=25°C typ)	1.7 V
VF (Tvj=25°C typ)	1.65 V
Voltage Class max	1200 V
