Panasonic 750W AC SERVO MOTOR MSMD082P1S 2500PR INCREMENTAL ENCODER MINAS A4 series motor
Panasonic AC Servo Motors (MSMD A4 Series)
MSMD-MINAS A4 Series (100-200V)
Panasonic's MINAS A4 series corresponds to even variation of load inertia. Offers real automatic gain tuning to low and high stiffness machines with a combination of an adaptive filter. Supports the vertical axis application where the load torque is different in rotational direction. Prevents the machine from over-traveling during automatic gain tuning with over-travel detecting function. Enables you to set and check while monitoring real-time automatic gain tuning conditions on the front panel.
Panasonic Servo Motor MSMD082P1S
|
Item |
Specifications |
|
Part Number |
MSMD082P1S |
|
Details |
Low inertia, Lead wire type, IP65 |
|
Family Name |
MINAS A4 Family |
|
Series |
MSMD Series |
|
Type |
Low inertia |
|
Enclosure |
IP65 |
|
Motor encoder connector |
Lead wire |
|
Voltage specifications |
200 V |
|
Rated output |
750 W |
|
Holding brake |
without |
|
Oil seal |
without |
|
Shaft |
Key-way, Shaft end, Center tap |
|
Rated torque (N ⋅ m) |
2.4 |
| Momentary Max. peak torque (N ⋅ m) |
7.1 |
|
Max. current (A (o-p)) |
17.0 |
|
Rated rotational speed (r/min) |
3000 |
|
Rated rotational Max. speed (r/min) |
4500 |
|
Rotary encoder specifications |
2500 P/r Incremental system |
|
Features |
10 W to 7.5 kW, Input power supply for Driver: Voltage DC 24 V/48 V・AC 100 V/200 V/400 V, 20 bit incremental・17 bit Absolute/Incremental encoder, Frequency response 2.3 kHz |
| Related Servo Motor |
MSMD011P1, MSMD011S1, MSMD012P1, MSMD012S1, MSMD021P1, MSMD021S1, MSMD022P1, MSMD022S1, MSMD041P1, MSMD041S1, MSMD042P1, MSMD042S1, MSMD082P1, MSMD082S1, MSMD5AZP1, MSMD5AZS1 |
1.About Regenerative brake frequency
The frequency of the motor's stops from the rated speed with deceleration without load.
If the load is connected, frequency will be defines as 1/(m+1), where m=load moment of inertia/rotor moment of inertia.
When the motor speed exceeds the rated speed, regenerative brake frequency is in inverse proportion to thesquare of (running speed/rated speed).
Power supply voltage is AC115 V（at 100 V of the main voltage),AC230 V（at 200 V of the main voltage).
If the supply voltage fluctuates, frequency is in inverse proportion to the square of (Running supply voltage)relative to the value in the table.
When regeneration occurs continuously such cases as running speed frequently changes or vertical feeding, consult us ora dealer.
2. About unlimited regenerative brake frequency
If the effective torque is within the rated torque, there is no limit in generative brake.
3. About recommended moment of inertia ratio of the load and the rotor
Consult us or a dealer if the load moment of inertia exceeds the specified value.
A Series Servo Drive
|
Servo Drive |
Description |
|
MADDT1205 |
A Series Servo Drive AC 200-240VAC Supply 10 AMP 240 V Load |
|
MADDT1205003 |
A Series Servo Drive AC 200-240VAC Supply 10 AMP 240 V Load |
|
MADDT1207 |
A Series Servo Drive AC 200-240VAC Supply 10 AMP 240 V Load |
|
MADDT1207003 |
Servo Drive 10 AMP 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MADKT1505CA1 |
AC Servo Driver Kit 200V 100W 3000rpm 0.32nm Brake, 3m Cable |
|
MADKT1505E |
Servo Drive 10 AMP 240V LOAD Lead Free RoHS Compliant (MSL) |
|
MADKT1507CA1 |
Servo Driver Ultra-High Response Frequency Command Input & Pulse Output |
|
MADKT1507E |
Servo Drive 10 AMP 240V LOAD Lead Free RoHS Compliant (MSL) |
|
MBDDT2210 |
Servo Drive 15 AMP 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MBDDT2210003 |
Servo Drive 15 AMP 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MBDKT2510CA1 |
Servo Driver MINAS A5II 400W 1.3nm 3000rpm 200V 20-bit |
|
MBDKT2510E |
A Series AC Servo Driver MINAS A5 |
|
MCDDT3520 |
Servo Driver 30A 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MCDDT3520003 |
Servo Drive 30 AMP 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MCDKT3520CA1 |
Servo Drive AC 200~240VAC Supply 30 AMP 240V Load |
|
MCDKT3520E |
Servo Drive 30 AMP 240V LOAD Lead Free Status RoHS Compliant (MSL) |
|
MDDA013A1A |
A Series Servo Drive 100W 0.1KW Medium Inertia |
|
MDDA023A1A |
A Series Servo Drive 200W 0.2KW |
|
MDDA043A1A |
A Series Servo Drive 400W 0.4KW |
|
MDDA053A1A |
A Series Servo Drive 500W 0.5KW |
|
MDDA083A1A |
A Series Servo Driver 750W 200-240V |
|
MDDA103A1A |
A Series Servo Driver 1KW |
|
MDDA153A1A |
A Series Servo Driver 1.5KW 200V |
|
MDDA203A1A |
Servo Driver 2KW 200-230V Input 106V Output 3-Phase |
|
MDDA253A1A |
A Series Servo Driver 2.5KW 200V |
|
MDDA303A1A |
A Series Servo Driver 3KW 200V |
|
MDDA353A1A |
A Series Servo Driver 3.5KW 200V |
|
MDDA3A3A1A |
A Series Servo Driver 30W 0.05KW |
|
MDDA403A1A |
A Series Servo Driver 4KW 200V |
|
MDDA453A1A |
A Series Servo Driver 4.5KW 200V |
|
MDDA503A1A |
A Series Servo Driver 5KW 200V |
|
MDDA5A3A1A |
A Series Servo Driver 50W 0.05KW |
