ALLEN BRADLEY Touch Screen 2711P-RDK15C PANELVIEW PLUS 1500 Color Touch Display module
Details of Touch Screen 2711P-RDK15C
The 2711P-RDK15C is a PanelView terminal that belongs to the PanelView Plus 1500 series. It is manufactured and designed by Allen-Bradley. The Allen-Bradley 2711P-RDK15C PanelView terminal features a keypad and a 15.0 inches color display. The resolution of the display is 1024 x 768 pixels and it has a high-bright luminance. The keypad’s keys include function, numeric, and navigation keys. This terminal requires a single power supply of 24 (18 to 32) Volts DC and 70 Watts maximum (2.9 Amps at 24 Volts DC). This external supply must be used only for the terminal and it must not be grounded because it is internally protected. The power consumption of this terminal is 160 VA maximum and its heat dissipation is 240 BTU per hour.
Prior to the installation and mounting of the Allen-Bradley 2711P-RDK15C PanelView terminal, users must determine the kind of enclosure that suits the terminal best, depending on the kind of environment it will be exposed to. It is important to protect the screen from ultraviolet or infrared rays since these will significantly decrease the life of the screen. The 2711P-RDK15C is not recommended to place the terminal on the south or west side of the cabinet, or it may absorb too much heat during the day. It is also recommended to leave minimum clearances on each side of the terminal to allow for an adequate level of ventilation. The temperature around the terminal should not exceed 55 degrees Celsius. This terminal has an approximate weight of 4.6 kilograms.
Similar HMI Touch Screen
Display Modules (700 to 1500 only)
| Model | Description |
|
2711P-RDK7C |
700 keypad color display |
|
2711P-RDT7C |
700 touch color display |
|
2711P-RDT7CM |
700 touch color display, marine certified |
|
2711P-RDB7C |
700 keypad and touch color display |
|
2711P-RDB7CM |
700 keypad and touch color display, marine certified |
|
2711P-RDT7CK |
Conformal-coated 700 touch color display |
|
2711P-RDK10C |
1000 keypad color display |
|
2711P-RDT10C |
1000 touch color display |
|
2711P-RDT10CM |
1000 touch display, marine certified |
|
2711P-RDB10C |
1000 keypad and touch color display |
|
2711P-RDB10CM |
1000 keypad and touch display, marine certified |
|
2711P-RDK12C |
1250 keypad color display |
|
2711P-RDT12C |
1250 touch color display |
|
2711P-RDT12AG |
1250 touch color display with antiglare overlay |
|
2711P-RDT12CK |
Conformal-coated 1250 touch color display |
|
2711P-RDT12H |
1250 high-bright touch color display |
|
2711P-RDB12C |
1250 keypad and touch color display |
|
2711P-RDK15C |
1500 keypad color display |
|
2711P-RDT15C |
1500 touch color display |
|
2711P-RDT15AG |
1500 touch color display with antiglare overlay |
|
2711P-RDB15C |
1500 keypad and touch color display |
Logic Modules (700 to 1500 only)
Standard Logic Modules for PanelView Plus Terminals
And CE Logic Modules for PanelView Plus CE Terminals
| Model | Description |
|
2711P-RP |
Logic module without flash/RAM memory, DC input |
|
2711P-RPD |
Logic module, without memory, isolated DC input, marine certified |
|
2711P-RPA |
Logic module without flash/RAM memory, AC input, marine certified |
|
2711P-RP1 |
Logic module with 64 MB flash/64 MB RAM, DC input |
|
2711P-RP1A |
Logic module with 64 MB flash/64 MB RAM, AC input, marine certified |
|
2711P-RP1D |
Logic module with 64MB, isolated DC input, marine certified |
|
2711P-RP2 |
Logic module with 128 MB flash/128 MB RAM, DC input Compatible with ViewPoint Software. |
|
2711P-RP2A |
Logic module with 128 MB flash/128 MB RAM, AC input, marine certified |
|
2711P-RP2D |
Logic module with 128MB, isolated DC input, marine certified |
|
2711P-RP2DK |
Conformal-coated logic module with 128MB, isolated DC input |
|
2711P-RP2K |
Conformal-coated logic module with 128 MB flash/128 MB RAM, DC input |
|
2711P-RP3 |
Logic module with 256 MB flash/256 MB RAM, DC input |
|
2711P-RP3A |
Logic module with 256 MB flash/256 MB RAM, AC input, marine certified |
|
2711P-RP3D |
Logic module with 256MB, isolated DC input, marine certified |
|
2711P-RP6 |
CE logic module with 128 MB flash/128 MB RAM, DC input |
|
2711P-RP6A |
CE logic module with 128 MB flash/128 MB RAM, AC input, marine certified |
|
2711P-RP6D |
CE logic module with 128MB, isolated DC input, marine certified |
|
2711P-RP6DK |
CE conformal-coated logic module with 128MB, isolated DC input |
|
2711P-RP6K |
CE conformal-coated logic module with 128 MB flash/128 MB RAM, DC input |
|
2711P-RP7 |
CE logic module with 256 MB flash/256 MB RAM, DC input |
|
2711P-RP7A |
CE logic module with 256 MB flash/256 MB RAM, AC input, marine certified |
|
2711P-RP7D |
CE logic module with 256 MB, isolated DC input, marine certified |
